Kramer VS-211HDxl

2x1:2 SDI Auto Switcher

  • Max. Data Rate — 3Gbps
  • Contact Closure or automatic switching

Download Specsheet

The VS−211HDxl is a high−performance automatic switcher for 3G HD−SDI video signals. When configured as a standby switcher, it switches to the secondary input when the primary input is lost.

  • Max. Data Rate — 3Gbps.
  • Multi–Standard Operation — SDI (SMPTE 259M and SMPTE 344M), HD–SDI (SMPTE 292M) & 3G HD–SDI (SMPTE 424M).
  • HDTV Compatible.
  • Control — Contact closure or automatic switching.
  • Automatic Standby Switching — Switches from the secondary input to the primary input when a primary signal is detected.
  • Primary Input — Selectable.
  • Active Input LED Indicators.
  • Compact DigiTOOLS™ — 3 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.


  • 2 SD/HD/3G HD–SDI video on BNC connectors


  • 2 SD/HD/3G HD–SDI video on BNC connectors

Max. Output Rate

  • 800mVpp/75Ω

Data Rate

  • Up to 2.97Gbps


  • Contact closure remote control, input default selection switch


  • AC

Power Consumption

  • 5V DC, 400mA

Included Accessories

  • Power supply, mounting bracket

Product Dimensions

  • 12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H

Product Weight

  • 0.2kg (0.4lbs) approx.

Shipping Dimensions

  • 23.20cm x 12.00cm x 8.90cm (9.13" x 4.72" x 3.50" ) W, D, H

Shipping Weight

  • 0.6kg (1.3lbs) approx.


  • Backup switching for broadcast.
  • Post–production.
